NEW! The safe choice for hospital wards

SCAN Afia XTK

The quality ScanAfia XTK hospital bed is the safe choice for hospital wards. The bed has been designed for use by healthcare professionals in hospitals, healthcare centres and similar facilities, and it fulfils the requirements of the new EN 60601-2-52:2010 standard for medical beds.

Although it can take loads up to 260 kg, the ScanAfia XTK hospital bed is still light and easy to manoeuvre, thanks to its double castors.  The design places emphasis on both ergonomic working and patient comfort and accessibility; its exceptionally low minimum height makes work easier for nurses and makes getting out of bed easier for patients.  The back section slide mechanism also improves patient comfort.

Our many years’ experience in designing and manufacturing hospital beds ensures that the ScanAfia XTK provides a long service life with minimal need for maintenance.

TECHNICAL FEATURES

  • Hand controller
  • Safe Working Load 260kg
  • Manual emergency lowering of back section
  • Back section slide
  • Lowest height only 30 cm (depending on model and castors)
  • 125 or 150 mm centrally lockable wheels and direction wheel, also twin castors
  • Removable ends, available in standard colours white, blue and green
  • Chrome plated or painted side rails; normal and long versions
  • Bumper rollers
  • Lengthening option available (15 cm)
  • Built-in place for lifting pole
  • Built-in place for two IV-poles
  • Safe 24V electrical system. Electrical components and connections earthed and splash-proof.
  • Breathable ABS plastic base with mattress holders
  • High quality powder coated finish, prepared for coating by abrasive blasting.

ACESORIESS

  • Lifting pole with triangle
  • Lift support
  • Urine bag holder
  • 5th wheel to assist moving
  • Bedding stand
  • Monitor stand
  • Nurse control panel
  • Nurse locking panel
  • Meal tray

NEW! Extremely Low and Easy to Move

SCAN Afia XS

The quality ScanAfia XS hospital bed is the safe choice for hospital wards. The bed has been designed for use by healthcare professionals in hospitals, healthcare centres and similar facilities, and it fulfils the requirements of the new EN 60601-2-52:2010 standard for medical beds.

Although it can take loads up to 260 kg (SWL), the ScanAfia XS hospital bed is still light and easy to manoeuvre, thanks to the optional choice of double castors. The design places emphasis on both ergonomic working and patient comfort and accessibility; its exceptionally low minimum height makes work easier for nurses and makes getting out of bed easier for patients. The back section slide mechanism also improves patient comfort. The bed also features an extremely broad Trendelenburg / Anti-Trendelenburg adjustment range.

THE RANGE

  • ScanAfia XS – 280/290
    2-part bed section (205 X 80/90 cm), with electrical height and back section adjustment.
  • ScanAfia XS – 480/490
    4-part bed section (205 X 80/90 cm), with electrical height, back, calf- and leg section adjustment.

TECHNICAL FEATURES

  • Hand controller
  • Safe Working Load (SWL) 260kg
  • Trendelenburg 12° / Anti-Trendelenburg 20°adjustment
  • Manual emergency lowering of back section
  • Back section slide
  • Lowest height only 32 cm (depending on model and castors)
  • Ø125 centrally lockable wheels and direction wheel option
  • Removable ends, available in standard colours white, blue, yellow and light green
  • Chrome plated or painted side rails; normal and long versions
  • Bumper rollers
  • Built-in place for lifting pole
  • Built-in place for two IV-poles
  • Breathable ABS plastic base with mattress holders

MAIN FEATURES

  • Ergonomic working position thanks to impressive height adjustment range
  • High safe working load (SWL): 260 kg
  • Easy to manoeuvre thanks to its double casters

FACTORY INSTALLED OPTIONS

  • Battery driven
  • 5th wheel to assist moving

OTHER ACCESSORIES

  • Special length (extendable +15 cm) model
  • Extra height side rails
  • IV-pole with one hand quick adjustment
  • Auxiliary tray (for linen)
  • Electric CPR
  • Bed end (head section)
  • Bed end with monitor tray
  • Urine bag holder
  • Reading and dining tray, on top of the side rails
  • Nurse locking panel (allows functions to be locked to prevent patient use)
  • Flexible hand controller holder
  • Bed ends: white, blue, yellow and light green

NEW! Versatile ICU-bed with extensive features

SCAN Afia X ICU

The quality ScanAfia X-ICU bed is a safe choice for hospital intensive care units. Practical design features provide excellent quality-price ratio. Scan Afia X-ICU bed also fulfils the requirements of the new EN 60601-2-52:2010 standard for medical beds.

Although it can take loads up to 340 kg (SWL), the ScanAfia X-ICU bed is still light and easy to manoeuvre, thanks to its Ø150mm design twin castors. As a unique feature you may also have electrically lockable set of castors. The design of the bed emphasizes both ergonomic working and patient comfort and accessibility; its exceptionally low minimum height makes work easier for nurses and makes getting out of bed easier for patients. The back section slide mechanism also improves patient comfort.

The bed also features an extremely broad electric Trendelenburg/Anti-Trendelenburg adjustment range. ScanAfia X-ICU’s standard features also include: nurse control panel, electric CPR function, back section
slide, battery function and extensive range of quality accessories.

THE RANGE

  • ScanAfia X ICU
    4-part bed section (205 X 80/90 cm), with electrical height, back, calf- and leg section adjustment. Electrical Trendelenburg / Anti-Trendelenburg

TECHNICAL FEATURES

  • Battery driven
  • Safe Working Load 340kg
  • Lowest height only 30 cm (depending on model and castors)
  • Electric Trendelenburg/ Anti-Trendelengburg, 12°/20°
  • Ø150 mm centrally lockable wheels and direction wheel
  • Removable ends, available in standard colours white, blue, yellow and light green
  • Chrome plated or painted side rails; normal and long versions
  • Hand controller
  • Nurse control panel
  • Back section slide
  • Electrical CPR-function
  • Manual emergency lowering of back section
  • Fixing hooks for supporting belts
  • Bumper rollers
  • Safe 24V electrical system. Electrical components and connections earthed and splash-proof.
  • Breathable ABS plastic base with mattress holders

MAIN FEATURES

  • Very high safe working load (SWL) of 340 kg
  • Very easy to manoeuvre thanks to large (150 mm) double casters
  • Up to 20° anti-Trendelenburg adjustment for effective heart position

FACTORY INSTALLED OPTIONS

  • 5th wheel to assist moving

OTHER ACCESSORIES

  • Special length (extendable +15 cm) model
  • Extra height side rails
  • Lifting pole with triangle handle
  • Lift support
  • IV-pole with one hand quick adjustment
  • Auxiliary tray (for linen)
  • Bed end (head section)
  • Bed end with monitor tray
  • Urine bag holder
  • Reading and dining tray, on top of the side rails
  • Flexible hand controller holder

Sturdy, functional and mobile

SALLI

The Salli hydraulic hospital bed is the ideal solution for clinics needing sturdy, functional and mobile hospital beds at a reasonable price. Based on the design of the popular ScanAfia range, Salli hydraulic beds feature modular construction, allowing flexibility to create models to meet the specific demands of the medical staff. Standard features include height adjustment, mechanical regulation of sections, removable bed end, Ø125 mm central locking castors, ABS plastic surface. Optional side rails (2 types), lifting pole, IV stand and wide range of other additional accessories make these beds exceptional tool for patient care.

THE RANGE

  • Salli Hydraulic Pro-280
    Two-part bed section with hydraulic adjustment of height and mechanically adjustable back support (gas spring adjustment optional)
  • Salli Hydraulic Pro-480
    Three-part bed section with hydraulic adjustment of height, mechanically adjustable back support and knee-break adjustment (gas spring adjustment optional for both)

TECHNICAL FEATURES

  • Hydraulic height adjustment, foot pedals on both sides of the bed, height range 46 – 81 cm
  • Central locking Ø125mm mm castors with steering castor
  • Safe working load 170 kg
  • ABS-plastic bed base, two or three sections, widths 80 cm or 90 cm
  • Optional metal mesh bed base (only available width 80 cm)
  • Integrated places for lifting pole (accessory)
  • Integrated places for IV-pole (accessory)
  • Bumpers
  • Steel parts are sandblasted before painting
  • Holder for wires during transportation
  • Removable bed ends for Salli models (one unit standard, choice of colours: white, blue or green)

MAIN FEATURES

  • Reliable hydraulic functions – no need for electricity
  • Easy steering – easy movability
  • Large number of accessories

FACTORY INSTALLED OPTIONS

  • Metal bed end, with tilting mechanism
  • Gas spring assisted adjustment for back section
  • Trendelenburg/reverse-Trendelenburg adjustment (only when castors are used)
  • IV pole, straight model
  • IV pole, curved model
  • Fifth castor for improved mobility, only for hydraulic models

OTHER ACCESSORIES

  • Bed end (head section)
  • Bed end with tilting mechanism
  • IV-pole, straight or curved
  • Lifting pole
  • Reading and dining tray, on top of the side rails
  • Lift support
  • Pair of metal side rails, epoxy coated/chromium coated
  • Pair of side rails, economy model (drop down model)
  • Bed ends: white, blue, yellow and light green

Easy to use, modular and functional

SALLI F

Simple, easy to use, modular and functional Salli fixed height hospital beds were created for every day patient care. Made out of high quality raw materials and components these beds have 10 years warranty for welded parts and may stand very severe usage. These low-cost models gained popularity in several countries and became Lojer’s bestseller for past years. Standard features include mechanical regulation of sections, removable bed end, ABS plastic surface. Optional side rails (2 types), lifting pole, IV stand, 125 mm. individual locking castors will add more to functionality of Salli fixed height beds.

THE RANGE

  • Salli F-1
    ABS-plastic bed base (fixed), a set of legs
  • Salli F-2
    ABS-plastic bed base, mechanical back section, a set of legs
  • Salli F-3
    ABS-plastic bed base, mechanical back section, mechanical knee-break adjustment, a set of legs

TECHNICAL FEATURES

  • Individually locking 125 mm castors as option
  • Safe working load 200 kg
  • ABS-plastic bed base, two or three sections, widths 80 cm or 90 cm
  • Optional metal mesh bed base (only available in width 80 cm)
  • Integrated places for lifting pole (accessory)
  • Integrated places for IV pole (accessory)
  • Bumpers
  • Steel parts are sandblasted before painting
  • Holder for wires during transportation
  • Removable bed ends for Salli models (one unit standard, choice of colours: white, blue or green)

FACTORY INSTALLED OPTIONS AND OTHER ACCESSORIES

  • Metal bed end, curved or straight, epoxy-coated or chromium plated
  • Metal bed end, with tilting mechanism
  • Pair of metal side rails (standard model), epoxy-coated or chromium plated
  • Pair of metal side rails, economy model (drop down model)
  • Set of individually locking castors (Ø125m) for fixed height models
  • Set of individually locking castors (Ø125m), for hydraulic models, price reduction
  • Gas spring assisted adjustment for back section
  • Gas spring assisted adjustment for knee-break, only for model Salli F-3
  • Mechanical adjustment for leg section, only for model Salli F-2
  • Trendelenburg/reverse-Trendelenburg adjustment (only when castors are used)
  • IV pole, straight model
  • IV pole, curved model
  • Lifting pole with attachment kit
  • Lift support
